1700°C Lab Sintering Furnace Muffle Furnace for Ceramic Sintering and Thermal Processing

Name: 1700C Lab Sintering Furnace Muffle Furnace for Ceramic Sintering and Thermal Processing
Brand: TENCAN
Price: 1 USD

Buy cheap 1700°C Lab Sintering Furnace Muffle Furnace for Ceramic Sintering and Thermal Processing product

Certification : CE

Product Type : Laboratory Box-Type Furnace

Temperature Control : 50-Segment Programmable PID Control

Safety Protection : Over-Heat Alarm Protection

Delivery Time : 7~15

Furnace Lining : Polycrystalline Mullite Fiber

Max Temperature : 1800°C

Heating Element : Resistance Wire Heating

Cooling Design : Double-Layer Shell with Fan Cooling

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Working Temperature : 1700°C

Application : Sintering, Melting and Material Analysis

MOQ : 1

Chamber Volume : 1L~729L, Customizable

Place of Origin : CHINA

Brand Name : TENCAN

Contact Now

1700°C Muffle Furnace for High-Temperature Thermal Processing

The 1700°C Muffle Furnace is designed for laboratories, universities, research centers, and industrial testing departments that require stable high-temperature performance for ceramic sintering, calcination, firing, material analysis, and thermal processing. It provides a closed heating chamber that helps maintain a clean processing environment and supports consistent heating results for different sample types.

This 1700°C electric box furnace is suitable for ceramics, metal oxides, mineral materials, inorganic compounds, powder samples, and other high-temperature research materials. It is widely used in material development, quality inspection, powder metallurgy, ceramic engineering, chemical testing, and small-batch experimental production.

The furnace adopts high-temperature insulation materials with low heat loss and strong thermal stability, helping improve heating efficiency while maintaining reliable chamber performance during repeated heating cycles. The reinforced chamber design enhances structural durability and supports long-term use under demanding operating conditions.

With accurate temperature control, steady heat distribution, and dependable safety protection, this 1700°C muffle furnace offers an efficient solution for users who need reliable high-temperature equipment for research, testing, and production preparation.

1700°C Lab Sintering Furnace Muffle Furnace for Ceramic Sintering and Thermal Processing

Product Features

Maximum temperature range: room temperature to 1800°C.
Available chamber capacities from 1 L to 1000 L.
Heating element options include FeCrAl resistance wire, U-shaped silicon carbide heating elements, and U-shaped molybdenum disilicide heating elements.
Customizable top-opening or side-opening door design helps keep operators away from direct heat exposure.
Intelligent 50-segment programmable automatic temperature control.
Built-in over-temperature alarm for safer operation.
Double-layer air-cooling structure with cooling fans helps keep the outer shell temperature below 60°C.

1200°C Box Furnace Technical Specifications

Model	Max. Temperature $° C$	Working Temperature $° C$	Chamber Size $W \times H \times D$ mm	Volume $L$	Power $k W$	Phase	Thermocouple Type
TC-12N-1	1200	1100	100×100×100	1	0.8	1	Type K
TC-12N-3	1200	1100	150×150×150	3	2.5	1	Type K
TC-12N-8	1200	1100	200×200×200	8	5	1	Type K
TC-12N-12	1200	1100	200×200×300	12	6	1	Type K
TC-12N-36	1200	1100	300×300×400	36	10	3	Type K
TC-12N-64	1200	1100	400×400×400	64	16	3	Type K
TC-12N-125	1200	1100	500×500×500	125	25	3	Type K
TC-12N-216	1200	1100	600×600×600	216	36	3	Type K
TC-12N-512	1200	1100	800×800×800	512	64	3	Type K
TC-12N-729	1200	1100	900×900×900	729	80	3	Type K

1400°C Box Furnace Technical Specifications

Model	Max. Temperature $° C$	Working Temperature $° C$	Chamber Size $W \times H \times D$ mm	Volume $L$	Power $k W$	Phase	Thermocouple Type
TC-14S-1	1400	1300	100×100×100	1	1	1	Type S
TC-14S-3	1400	1300	150×150×150	3	3	1	Type S
TC-14S-8	1400	1300	200×200×200	8	5	1	Type S
TC-14S-12	1400	1300	200×200×300	12	7	1	Type S
TC-14S-36	1400	1300	300×300×400	36	11	3	Type S
TC-14S-64	1400	1300	400×400×400	64	18	3	Type S
TC-14S-125	1400	1300	500×500×500	125	27	3	Type S
TC-14S-216	1400	1300	600×600×600	216	40	3	Type S
TC-14S-512	1400	1300	800×800×800	512	70	3	Type S
TC-14S-729	1400	1300	900×900×900	729	88	3	Type S

1700°C Box Furnace Technical Specifications

Model	Max. Temperature $° C$	Working Temperature $° C$	Chamber Size $W \times H \times D$ mm	Volume $L$	Power $k W$	Phase	Thermocouple Type
TC-17M-1	1700	1600	100×100×100	1	1	1	Type B
TC-17M-3	1700	1600	150×150×150	3	4	1	Type B
TC-17M-8	1700	1600	200×200×200	8	7	1	Type B
TC-17M-12	1700	1600	200×200×300	12	8	1	Type B
TC-17M-36	1700	1600	300×300×400	36	12	3	Type B
TC-17M-64	1700	1600	400×400×400	64	20	3	Type B
TC-17M-125	1700	1600	500×500×500	125	30	3	Type B
TC-17M-216	1700	1600	600×600×600	216	45	3	Type B
TC-17M-512	1700	1600	800×800×800	512	80	3	Type B
TC-17M-729	1700	1600	900×900×900	729	96	3	Type B

1800°C Box Furnace Technical Specifications

Model	Max. Temperature $° C$	Working Temperature $° C$	Chamber Size $W \times H \times D$ mm	Volume $L$	Power $k W$	Phase	Thermocouple Type
TC-18HM-1	1800	1700	100×100×100	1	2	1	Type B
TC-18HM-3	1800	1700	150×150×150	3	6	1	Type B
TC-18HM-8	1800	1700	200×200×200	8	8	1	Type B
TC-18HM-12	1800	1700	200×200×300	12	9	1	Type B
TC-18HM-36	1800	1700	300×300×400	36	15	3	Type B
TC-18HM-64	1800	1700	400×400×400	64	25	3	Type B
TC-18HM-125	1800	1700	500×500×500	125	35	3	Type B
TC-18HM-216	1800	1700	600×600×600	216	50	3	Type B

Note: The above specifications are standard models. Custom chamber sizes and configurations are available upon request.

Related Accessories

Standard Accessories

Furnace door insulation brick
High-temperature gloves
Crucible tongs
User manual
Spare heating elements for 1400°C and 1700°C models

Optional Accessories

HD touchscreen controller
Exhaust port
Observation window
Multi-layer kiln furniture
Alumina crucible
Communication software
